Features
Powerful brightness – Reduced surface exposure
- Quick and easy install in a few minutes
- 1/8” recessed body, freeing up space in the work area.
- 1/10” thick flange; Perfectly leveled and tightly binds to the machine mounting surface.
- Clearance for spindle and moving tools.
Built for Resistance
- Impenetrable enclosure
- Intense and uniform lumen output @ 5000K
- 24 Vdc built-in Drivers,
- A 10-foot cord or M12 connector Electrical service
- IP67 is resistant to oil, coolants, lubricants, and dust.
- IP69 reliable in high-pressure washing areas
- 4 years warranty
- Reparable in 10 years of work in harsh applications
Play Video
Play Video
Play Video
Mounting
Version
VEGA
| Order Code | Power Usage | Power Supply | Dimension | Beam angle | Flow Beam | Electric Service | Datasheet |
|---|---|---|---|---|---|---|---|
| VE0221S01 | 13 W | 24Vdc | 13.62 x 3.31 x 1.28" | 120 | 1300 Lumen | Cable 10 ft. |  |
| VE0221S02 | 13 W | 24Vdc | 13.62 x 3.31 x 1.28" | 120 | 1300 Lumen | M12-A 4P M | |
| VE0321S01 | 19.5 W | 24Vdc | 18.35 x 3.31 x 1.28" | 120 | 2000 Lumen | Cable 10 ft. | |
| VE0321S02 | 19.5 W | 24Vdc | 18.35 x 3.31 x 1.28" | 120 | 2000 Lumen | M12-A 4P M | |
| VE0521S01 | 32.5 W | 24Vdc | 27.80 x 3.31 x 1.28" | 120 | 3300 Lumen | Cable 10 ft. | |
| VE0521S02 | 32.5W | 24Vdc | 27.80 x 3.31 x 1.28" | 120 | 3300 Lumen | M12-A 4P M | |
| SALES SUMMARY | | Installation Manual | |
