TRACKALPHA PRO SERIES

Discover the improved Trackalpha PRO machine lights

Trackalpha PRO surface-mount machine lights are the solution for:

  • CNC machines
  • Manufacturing operations
  • Automation applications
  • Medium and large machine tools

Their robust aluminum housing is vibration resistant and, most importantly, it’s safe. This series is perfect for retrofitting old machines, thus it’s easy to install in pre-existing spaces. And there’s more.

We wanted to create a multipurpose, always-fitting luminaire. So we created Trackalpha series with a 120 Vac integrated power supply: the easiest and fastest way to install this operator-friendly device. The new, improved luminous flux is stable and even. No more mistakes and no more eye fatigue.

Obviously, we didn’t change a bit of what made this strong, reliable luminaire the most loved among its peers. Its aluminium housing for example, or the strong, protective front glass, transforming this machine light into a real warrior.

TRACKALPHA PRO IS MULTIPURPOSE

THE CLEAR VISION YOU WANTED. These luminaires bring to the table a never-before-seen improved optics, giving a limpid vision to each operation. Their light color temperature is 5000 K and they have a CRI 80.

JUST CONNECT IT. This series presents a new kind of connection. The direct 120 Vac integrated power supply delivers the best lighting wherever you want. Versatile and flexible, it gives you top freedom thanks to its connections: a M12 connector or a 10 ft. cable. Just pick yours.


SAFER AND STRONGER THAN EVER

Its legendary resistance is due to its aluminum alloy housing giving it extreme durability even when exposed to oils, coolants, lubricants, and dust.

Its front protection is made of hardened frosted glass 3/16” thick, debris, coolants and lubricants resistant. It won’t change it’s color by cause of the contact with oils and the quality of it’s light won’t decrease. The luminaire’s IP level is IP67, meaning it’s watertight and hermetic to dusts and microparts.

Trackalpha PRO series has a IK06 level, meaning it’s not afraid of high-velocity metal chippings and splinters. It just won’t break.

THE BEST RETROFITTING COMPANION

The Trackalpha PRO series is the best flexible solution to retrofit old machines, thanks to the combination of a 2 ¾” diameter housing, a M12 connector, and universal mounting brackets. The direct connection is the key: no need to adjust the space inside the machine, nor to change anything in your existing configuration. You won’t add any other component either. You’ll get what you see.

Given its 8 available set ups coming in 4 different lengths, this series of luminaires is suitable for countless applications.  Trackalpha PRO is not a mere accessory, but it’s going to become part and parcel of the machine, a support in every industrial function.

PLACE IT JUST WHERE YOU NEED IT

The installation process is quick and easy. Two standard mounting options are available: rear clips or side mounting brackets.

  • Rear clips:  sturdy, flexible and vibration resistant, they give a 30° angle adjustment. Made of anodized aluminum, it is the perfect solution if you need to retrofit outdated machine tools and machining centers.
  • Side mounting brackets: robust, versatile and vibration resistant, they allow a 70° angle adjustment. Made of stainless steel, they are the perfect solution when you need to adjust the direction of the flow beam in highly vibrating applications. They work well with the strong magnet in neodymium B03. in highly vibrating applications.

These standard fixing allow a precise adjustment of the light direction up to 90°, while providing secure clamping and manageable installation of the luminaires.

INTEGRATED POWER SUPPLY

HARDENED FROSTED GLASS

4 DIFFERENT LENGHTS

Mounting

TACLIP - REAR CLIPS fixing option

TACLIP – REAR CLIPS

TAFX02 - SIDE MOUNTING BRACKETS FOR TRACKALPHA PRO

TAFX02 – SIDE MOUNTING BRACKETS

B03 - NEODYMIUM MAGNET FOR TRACKALPHA PRO

B03 – NEODYMIUM MAGNET

Version

TRACKALPHA PRO

Order CodePowerPower SupplyLengthOpening AngleFlow BeamConnectionDatasheet
Sales SummaryDownloadInstallation ManualDownload
TA0224S0113 W120Vac12.64×2.76×2.24 "120 °1300lmM12-A 4P MaleDownload
TA0224S0213 W120Vac12.64×2.76×2.24 "120 °1300lm10ft M12 cableDownload
TA0324S0119.5W120Vac17.36×2.76×2.24 "120 °1950lmM12-A 4P MaleDownload
TA0324S0219.5W120Vac17.36×2.76×2.24 "120 °1950lm10ft M12 cableDownload
TA0524S0132.5 W120Vac26.81×2.76×2.24 "120 °3250lmM12-A 4P MaleDownload
TA0524S0232.5 W120Vac26.81×2.76×2.24 "120 °3250lm10ft M12 cableDownload
TA0724S0145.5 W120Vac36.26×2.76×2.24 "120 °4550lmM12-A 4P MaleDownload
TA0724S0245.5 W120Vac36.26×2.76×2.24 "120 °4550lm10ft M12 cableDownload
